Universal Dryer Cycling Thermostat, 120°F

Supco Universal L120 LS2-120 Dryer Cycling Thermostat. The L Series of 3/4" (19mm) bimetal disc temperature controls offers proven reliability in a versatile, cost-effective design. The cycling thermostat monitors and regulates the temperature inside the dryer.

Differential: 10°
Open (°F): 120°
Close (°F): 110°
Amperage (Full Load) @ 120VAC: 14A
Amperage (Full Load) @ 240VAC: 10A
Amperage (Locked Rotor) @ 120VAC: 72A
Amperage (Locked Rotor) @ 240VAC: 60A
Pilot Duty @ 120VAC / 240VAC: 125 VA
Amperage (Resistive) @ 120VAC / 240VAC: 25A

Possible Repair Solution For:
Not drying properly, will not start, no heat, not enough heat, too hot, drying ends too soon.

Please Note: This is intended as a guideline only, as other items can cause the same symptoms.

This part is also known as an operating thermostat, L120-10F.
