Universal Dryer Cycling Thermostat, 170°F

Supco Universal LD170 LS3-170 Dryer Cycling Thermostat. The L Series of 3/4" (19mm) bimetal disc temperature controls offers proven reliability in a versatile, cost-effective design. The cycling thermostat monitors and regulates the temperature inside the dryer.

Differential: 20°
Open (°F): 170°
Close (°F): 150°
Motor rating(inductive)FL @ 120VAC: 14A
Motor rating(inductive)FL @ 240VAC: 10A
Motor rating(inductive)LR @ 120VAC: 72A
Motor rating(inductive)LR @ 240VAC: 60A
Pilot Duty @ 120VAC: 125 VA
Pilot Duty @ 240VAC: 125 VA

Possible Repair Solution For:
Not drying properly, will not start, no heat, not enough heat, too hot, drying ends too soon.

Please Note: This is intended as a guideline only, as other items can cause the same symptoms.

This part is also known as an operating thermostat, L170-20F.
